ILM62CMD20A000 is listed by Schneider Electric as a connection module in the Lexium 62 ILM range, associated on the manufacturer’s product page with reference LXM62PD84A11000. When checking the code, do not confuse it with the similarly prefixed ILM62DB4A000 distribution box. The catalogue assigns the two products different functions, dimensions and protection ratings; that does not establish that they are interchangeable or confirm how they are used together.
What does ILM62CMD20A000 identify?
Schneider Electric’s product page identifies ILM62CMD20A000 as a connection module and names reference LXM62PD84A11000. The manufacturer’s catalogue describes the module’s role as connecting the Lexium 62 ILM with Sercos and the DC bus. This helps identify a product record; it does not approve a replacement, wiring arrangement or fit for a particular machine.
A similar product name, a shared family prefix or a listing that simply says “Lexium 62” is not enough to prove a match. Compare the full code on the label and the manufacturer’s reference exactly.
Technical values listed in the manufacturer’s catalogue
| Check | Catalogue entry for ILM62CMD20A000 |
|---|---|
| Product type | Lexium 62 ILM connection module |
| Current | 20 A input; 20 A output |
| Continuous output | 0.95 kW |
| DC bus | 250–700 V DC input and output |
| Control voltage | 24 V DC (−20%…+25%) |
| Cooling and protection | Passive cooling; IP20 |
| Housing dimensions | Depth × width × height: 270 × 44.5 × 310 mm |
| Weight | 3 kg |
Use these entries to check the model and documentation. Do not interpret 20 A or 0.95 kW alone as proof of machine power or motor suitability. Dimensions also do not, by themselves, prove mounting clearance or connector alignment.
Check the code difference from ILM62DB4A000
Schneider’s catalogue lists ILM62DB4A000 as a Lexium 62 ILM distribution box, not a connection module. The same table gives it a weight of 0.85 kg, IP65 protection and dimensions of 151.4 × 230 × 94 mm. These differences are why the full manufacturer code and product description matter more than the family name alone. Have qualified technical personnel confirm which item is required for the machine using its existing diagram and manufacturer documentation.
What information should you send with a quote request?
- Record the complete code from the product label, including zeros and punctuation; include a readable label photo if available.
- Share the model references on the machine, drive and power supply. Compare the LXM62PD84A11000 reference named by the manufacturer with the existing record.
- Document the existing part’s dimensions, connector views and any visible serial or revision information. A photo alone does not prove physical fit.
- State the quantity and destination country. Price, condition, availability and lead time are confirmed during quotation.
Do not open an energized cabinet or handle its connections. This article is not an installation, wiring, commissioning or electrical product-selection guide. Confirm system suitability against manufacturer documents with qualified technical personnel.
Manufacturer sources and the Belfa product record
For the model description and technical table, consult Schneider Electric’s ILM62CMD20A000 product page and page 7 of the Lexium 62 ILM catalogue. Belfa Makine’s Schneider Electric ILM62CMD20A000 product listing is for this exact reference; commercial terms are confirmed during quotation.
Frequently asked questions
What part does ILM62CMD20A000 identify?
Schneider Electric lists it as a Lexium 62 ILM connection module and names reference LXM62PD84A11000. Suitability for a particular machine must be confirmed separately.
Are ILM62CMD20A000 and ILM62DB4A000 the same part?
No. The manufacturer’s catalogue describes the first as a connection module and the second as a distribution box. Check the codes, descriptions and dimensions separately; do not assume they are interchangeable.
What are the dimensions and weight of ILM62CMD20A000?
Schneider’s catalogue lists the housing as 270 × 44.5 × 310 mm (depth × width × height) and weight as 3 kg. Check the label and drawing of the actual part as well.
This article was prepared automatically by Belfa Makine using manufacturer catalogue information and search needs. Verify the full manufacturer code and application reference before ordering.
